ABB PSTX570 - Dimensions PSTX210-PSTX570; PSTX210 to PSTX370 Dimensions; PSTX470 to PSTX570 Dimensions

Softstarters Type PSTX30...PSTX570 User Manual short form 1SFC132059M9901 245
PSTX210...PSTX370
PSTX470...PSTX570
260 mm (10,2 in)
276 mm (10,9 in)
470 mm (18,5 in)
451 mm (17,8 in)
10,5 mm (0,4 in)
389 mm (15,3 in)
5 mm (0,2 in)151 mm (5,9 in)
M6 (1/4 in)
3
200 mm (7,9 in)
258 mm (10,2 in)
43,7 mm (1,7 in) 4x
19,6 mm (0,8 in) 6x
1SFC132082M9901
02
4
1SFC132082M9901
336 mm (13.2 in)(2x)
460 mm (18.1 in)
63 mm (2.5 in)(4x)
493 mm (19.4 in) 466 mm (18.3 in)
9 mm (0.3 in)
361 mm (14.2 in)
282.15 mm (11.1 in)
262.82 mm (10.3 in)
25 mm (1 in)(6x)
6 mm (0.2 in)
58.2 mm (2.3 in)
R3.5(4x)
R6.5(4x)
M6 (1/4 in
)
