ABB PSTX570 - Control Supply Wiring; Wiring Diagram for Control Supply (08); Wiring Diagram for Functional Earth (09)

Softstarters Type PSTX30...PSTX570 User Manual short form 1SFC132059M9901 249
1SFC132082M9901
0,2 .. 2,5 mm
2
2x0,2 .. 1,5 mm
2
0,2 .. 2,5 mm
2
2x0,2 .. 1,5 mm
2
AWG 12 ... 24
0,5 Nm
4,3 lb.in
3,5 x 0,6 mm
(0.138 x 0.024 in)
1SFC132082M9901
M3,5
L
100-250V
50/60 Hz K4 K5 K6
StartStopIn0 In1In2 GND +24V
N
0,2 .. 2,5 mm
2
2x0,2 .. 1,5 mm
2
0,2 .. 2,5 mm
2
2x0,2 .. 1,5 mm
2
AWG 12 ... 24
0,5 Nm
4,3 lb.in
3,5 x 0,6 mm
(0.138 x 0.024 in)
1SFC132082M9901
M3
L
100-250V
50/60 Hz K4 K5 K6
StartStopIn0 In1In2 DGND GND +24V
N
1SFC132082M9901
08
09
