1SFC132081M0201 | Installation and commissioning manual | Functions 139
Parameter
number
Description Setting range Number of
decimals
Fieldbus
ID
Default value Actual
setting
18 Protections list 6
18.01 User defined DI status Active low, Active high 0 251 Active high
18.02 User defined trip time 0.0 ... 60.0 s 1 252 1.0 s
18.03 User defined out
Eventgroup 0 ... 6
0 90 0000010
18.04 User defined op Off, Stop-Manual, Stop-Automatic, Indication 0 253 Off
18.05 Ground fault trip time 0.1 ... 1.0 s 1 73 0.5 s
18.06 Ground fault out
Eventgroup 0 ... 6
0 75 0000010
18.07 Ground fault op Off, Stop-Manual, Stop-Automatic, Indication 0 74 Off
18.08 Too long curr lim trip time 1 ... 600 s 0 254 10 s
18.09 Too long curr lim out
Eventgroup 0 ... 6
0 255 0000010
18.10 Too long curr lim op Off, Stop-Manual, Stop-Automatic,
Indication. Fast ramp
0 256 Off
18.11 Too long start trip time 1.0 ... 500.0 s 1 500.0 s
18.12 Too long start out Eventgroup 0 ... 6 0 0000010
18.13 Too long start op Off, Stop-Manual, Stop-Automatic, Indication 0 Off
18.14 Auto-restart max delay 2 ... 3600 s 0 3600
18.15 Auto-restart time-out out Eventgroup 0 ... 6 0 0000010
18.16 Auto-restart time-out op Off, Stop-Manual, Stop-Automatic, Indication 0 Off
19 Protections list 7
19.01 HMI failure out
Eventgroup 0 ... 6
0 100 0000010
19.02 HMI failure op Off, Stop-Manual, Stop-Automatic,
Indication, Switch of HMI control
0 257 Stop-Manual
19.03 Fieldbus failure out
Eventgroup 0 ... 6
0 97 0000010
19.04 Fieldbus failure op Off, Stop-Manual, Stop-Automatic,
Indication, Switch to I/O control
0 258 Stop-Manual
19.05 Ext IO failure trip time 300 ... 30000 ms 0 259 1000 ms
19.06 Ext IO failure out
Eventgroup 0 ... 6
0 99 0000010
19.07 Ext IO failure op Off, Stop-Manual, Stop-Automatic, Indication 0 260 Stop-Manual
20 Warnings list 1
20.01 EOL level 40.0 ... 99.0% 1 181 90.0%
20.02 EOL out
Eventgroup 0 ... 6
0 123 0000100
20.03 EOL warning On / Off 0 182 Off
20.04 Locked rotor level 0.2 ... 10.0 x
I
e
1 261 1.2 x I
e
20.05 Locked rotor init time 1.0 ... 30.0 s 1 262 5.0 s
20.06 Locked rotor out
Eventgroup 0 ... 6
0 125 0000100
20.07 Locked rotor On / Off 0 263 Off
20.08 Thyristor OL out
Eventgroup 0 ... 6
0 124 0000100
20.09 Thyristor OL On / Off 0 122 Off
20.10 Locked rotor trip time 0.1 ... 100.0 s 1 - 0.1 s
21 Warnings list 2
21.01 Curr underload level 0.4 ... 1.0 x I
e
1 264 0.8 x I
e
21.02 Curr underload trip time 0 ... 10 s 0 265 1 s
21.03 Curr underload delay time 0 ... 30 s 0 266 5 s
21.04 Curr underload out
Eventgroup 0 ... 6
0 126 0000100
21.05 Curr underload On / Off 0 267 Off
21.06 Pwr factor underload level 0.00 ... 1.00 2 268 0.70
21.07 Pwr factor underload trip
time
0 ... 10 s 0 269 1 s
21.08 Pwr factor underload delay
time
0 ... 30 s 0 270 5 s
21.09 Pwr factor underload out
Eventgroup 0 ... 6
0 127 0000100
21.10 Pwr factor underload On / Off 0 271 Off
21.11 Current imb level 10 ... 80% 0 102 70%
21.12 Current imb out
Eventgroup 0 ... 6
0 103 0000100
21.13 Current imbalance On / Off 0 101 Off
