162 Troubleshooting | Installation and commissioning manual | 1SFC132081M0201
Event code* Motor control states **
(Hexadecimal)
Stand by
Start prerequisites
Pre-start
Init start
Start Ramp
Close bypass
Top of ramp
Open bypass
Stop ramp
Separate func
Faults
High current F02xx X X X X X X X X X X
Phase loss F03xx X X X X X X X X
Heatsink overtemperature F04xx X X X X X X X X X X
Bad network quality F05xx X X X X
Shunt fault F06xx X X X X
Low supply voltage
F07xx X X X X X X X X X X
Thyristor overload F08xx X X X X X X X X X X
Short circuit thyristor F09xx X X X X X
Open circuit thyristor F0Axx X X X X
Unspecified fault F0Bxx X X X X X X X X X X
Invalid ID F0Cxx X X X X X X X X X X
Faulty connection F0Dxx X
Faulty usage F0Exx X X X
Warnings
Current imbalance W23xx X
Current underload W24xx X
Fan failure W25xx X X X X X X X X X X
EOL warning W26xx X X X X X X X X X X
Locked rotor W27xx X
Overvoltage W28xx X
Under voltage W29xx X
Power factor underload W2Axx X
THD(U) W2Bxx X
Thyristor overload W2Cxx X X X X X X X X X X
Voltage imbalance W2Dxx X X X X X X X X
Short circuit W2Exx X X X X X
EOL time-to-trip W2Fxx X
Phase loss W30xx X
Number of starts limit W34xx X X X X X X X X X X
Motor run time limit W35xx X X X X X X X X X X
* Only the first 2 digits are important
** For motor control states description, see chapter 7 Functions
