RARIC
Shaft current protection
1MRK 502 001-UEN
Page 11
Alarm circuits (RXKL1, RXTUG22H/RXIK1)
Max. system voltage within a
contact set 250/250 V dc
250/250 V ac
Current-carrying capacity for already
closed contact 30/– A for 200 ms
15/10 A for 1 s
5/4 A continuously
Making and conducting capacity,
L/R < 10 ms 30/20 A for 200 ms
10/10 A for 1 s
Breaking capacity, dc, L/R < 40 ms 2/1,5 A at 24 V
1/0,5 A at 48 V
0,4/0,2 A at 110 V
0,2/0,1 A at 220 V
7DEOH
Weights and dimensions
Weight
RARIC , version 1
RARIC , version 2
ILDD
4 kg
5 kg
10 + 80(D - 300) / 2300 kg
where D is the inner diameter in mm
Dimension
RARIC , version 1
RARIC , version 2
ILDD
4U 24C
4U 36C
See Fig. 11
Table 4: Contact data
