RARIC
Shaft current protection
1MRK 502 001-UEN
Page 15
Fig. 11 Dimensions of the shaft current transformer ILDD. The measur-
ing windings of the two halves are interconnected via the termi-
nals S. All dimensions are in mm.
Transformer with D ≤ 2000 mm has the cross-section dimensions accord-
ing to Alt. 1.
Transformer with D > 2000 mm is split up in four parts and has the cross-
section according to Alt. 2.
Max 70
38
50
Alt. 1
42
65
Max 85
Alt. 2
D
±
5
A
Q
T
r
a
f
o
A
B
B
A
S2
S1S
en02000669.vsd
S
