ABB REA 10 Series - REA 103 Dimensions; REA 105 Dimensions; REA 107 Dimensions

Arc Protection Relay REA 10_
1MRS750929-MBG
13
Fig. 7 Dimensions of REA 103
44.6
203.3
182.6
170.3
160.5
ø
5.0
dim103
Fig. 8 Dimensions of REA 105
49.6
203.3
182.6
170.3
160.5
ø
5.0
dim105
Fig. 9 Dimensions of REA 107
dim107
