Arc Protection Relay REA 10_
1MRS750929-MBG
12
Dimensions Dimension drawings
Mounting alternatives
Fig. 4 Dimensions of REA 101
dim1_3
148,8
265,9
130,8
255,8
190
204,1
235
245,1
ABB
482.6
With protective
cover
Without
protective
cover
Fig. 5 Flush mounting and semi-flush mounting of REA 101
4-10
ABB
flush1_3
16,5
D
135,2
±1
254,3
±1
>20
~15
Measure D:
218.5 mm without protective cover
228,6 mm with protective cover
semifl1_3
D
106,5
Measure D:
128,5 mm without
protective cover
138.6 mm with
protectivecover
Fig. 6 Surface mounting of REA 101
wallmoun.
A
B
C
Wall
M4x6 TORX
M5x8 TORX
M6x12 TORX
