ABB REB650 - Page 244

KIOSK 2
KIOSK 3
Station HSI
Base System
Engineering
Workstation
SMS
Gateway
Printer
CC
IEC09000135_en.v
sd
KIOSK 1
IED
1
IED
2
IED
3
IED
1
IED
2
IED
3
IED
1
IED
2
IED
3
IEC09000135 V1 EN-US
Figure 79: SA system with IEC 61850–8–1
M16925-3 v4
Figure80 shows the GOOSE peer-to-peer communication.
Control Protection Control ProtectionControl and protection
GOOSE
en05000734.vsd
Station HSI
MicroSCADA
Gateway
IED
A
IED
A
IED
A
IED
A
IED
A
IEC05000734 V1 EN-US
Figure 80: Example of a broadcasted GOOSE message
Section 15 1MRK 505 388-UEN B
Station communication
238 Busbar protection REB650 2.2 IEC
Application manual
