ABB REB650 - Page 32

IEC 61850 or
function name
ANSI Function description Busbar
REB650 (A03)
SMAGAPC General start matrix block 6
TMAGAPC Trip matrix logic 12
ALMCALH Logic for group alarm 5
WRNCALH Logic for group warning 5
INDCALH Logic for group indication 5
AND, GATE, INV,
LLD, OR,
PULSETIMER,
RSMEMORY,
SRMEMORY,
TIMERSET, XOR
Basic configurable logic blocks (see Table 3) 40–420
FXDSIGN Fixed signal function block 1
B16I Boolean to integer conversion, 16 bit 18
BTIGAPC Boolean to integer conversion with logical node representation, 16 bit 16
IB16 Integer to Boolean 16 conversion 18
ITBGAPC Integer to Boolean 16 conversion with Logic Node representation 16
TEIGAPC Elapsed time integrator with limit transgression and overflow
supervision
12
INTCOMP Comparator for integer inputs 30
REALCOMP Comparator for real inputs 30
Table 3: Total number of instances for basic configurable logic blocks
Basic configurable logic block
Total number of instances
AND 280
GATE 40
INV 420
LLD 40
OR 298
PULSETIMER 40
RSMEMORY 40
SRMEMORY 40
TIMERSET 60
XOR 40
IEC 61850 or
function name
ANSI Function description Busbar
REB650 (A03)
Monitoring
CVMMXN Power system measurement 6
CMMXU Current measurement 10
Table continues on next page
Section 2 1MRK 505 388-UEN B
Application
26 Busbar protection REB650 2.2 IEC
Application manual
