ABB REB650 - Page 18

Function name Signal type Signal name Description
BI4 Binary input 4
BI5 Binary input 5
BI6 Binary input 6
BI7 Binary input 7
BI8 Binary input 8
BI9 Binary input 9
BI10 Binary input 10
BI11 Binary input 11
BI12 Binary input 12
BI13 Binary input 13
BI14 Binary input 14
BI15 Binary input 15
BI16 Binary input 16
OSCWRN Oscillation warning
BOM Binary inputs STATUS Binary output part of BOM module status
BLOCK Block binary outputs
BO1 Binary output 1
BO2 Binary output 2
BO3 Binary output 3
BO4 Binary output 4
BO5 Binary output 5
BO6 Binary output 6
BO7 Binary output 7
BO8 Binary output 8
BO9 Binary output 9
BO10 Binary output 10
BO11 Binary output 11
BO12 Binary output 12
BO13 Binary output 13
BO14 Binary output 14
BO15 Binary output 15
BO16 Binary output 16
BO17 Binary output 17
BO18 Binary output 18
BO19 Binary output 19
BO20 Binary output 20
BO21 Binary output 21
BO22 Binary output 22
BO23 Binary output 23
BO24 Binary output 24
IOM Binary inputs STATUS Binary input part of IOM module status
BI1 Binary input 1
BI2 Binary input 2
BI3 Binary input 3
BI4 Binary input 4
BI5 Binary input 5
BI6 Binary input 6
Table continues on next page
