Function name Signal type Signal name Description
BI7 Binary input 7
BI8 Binary input 8
BLKOUT Block binary outputs
BO1 Binary output 1
BO2 Binary output 2
BO3 Binary output 3
BO4 Binary output 4
BO5 Binary output 5
BO6 Binary output 6
BO7 Binary output 7
BO8 Binary output 8
BO9 Binary output 9
BO10 Binary output 10
BO11 Binary output 11
BO12 Binary output 12
OSCWRN Oscillation warning
General command handling from DNP master
AUTOBITS Binary outputs CMDBIT1 Command out bit 1
CMDBIT2 Command out bit 2
CMDBIT3 Command out bit 3
CMDBIT4 Command out bit 4
CMDBIT5 Command out bit 5
CMDBIT6 Command out bit 6
CMDBIT7 Command out bit 7
CMDBIT8 Command out bit 8
CMDBIT9 Command out bit 9
CMDBIT10 Command out bit 10
CMDBIT11 Command out bit 11
CMDBIT12 Command out bit 12
CMDBIT13 Command out bit 13
CMDBIT14 Command out bit 14
CMDBIT15 Command out bit 15
CMDBIT16 Command out bit 16
CMDBIT17 Command out bit 17
CMDBIT18 Command out bit 18
CMDBIT19 Command out bit 19
CMDBIT20 Command out bit 20
CMDBIT21 Command out bit 21
CMDBIT22 Command out bit 22
CMDBIT23 Command out bit 23
CMDBIT24 Command out bit 24
CMDBIT25 Command out bit 25
CMDBIT26 Command out bit 26
CMDBIT27 Command out bit 27
CMDBIT28 Command out bit 28
CMDBIT29 Command out bit 29
CMDBIT30 Command out bit 30
Table continues on next page
