Function name Signal type Signal name Description
CMDBIT31 Command out bit 31
CMDBIT32 Command out bit 32
General functions for showing signals for DNP master
MVGAPC Analog inputs IN Magnitude of deadband value
SP16GAPC Binary inputs IN1 Input 1 status
IN2 Input 2 status
IN3 Input 3 status
IN4 Input 4 status
IN5 Input 5 status
IN6 Input 6 status
IN7 Input 7 status
IN8 Input 8 status
IN9 Input 9 status
IN10 Input 10 status
IN11 Input 11 status
IN12 Input 12 status
IN13 Input 13 status
IN14 Input 14 status
IN15 Input 15 status
IN16 Input 16 status
OUTOR Output status logic OR gate for input 1 to 16
SPGAPC Binary inputs OUT Output status
Directly linked signals
ACTVGRP Binary inputs GRP1 Setting group 1 is active
GRP2 Setting group 2 is active
GRP3 Setting group 3 is active
GRP4 Setting group 4 is active
GRP5 Setting group 5 is active
GRP6 Setting group 6 is active
AEGPVOC Binary inputs TRIP Trip signal from accidental energizing of generator protection
B16I Analog inputs OUT Output value
BRCPTOC Binary inputs TRIP Operate signal of the protection logic
BTIGAPC Analog inputs OUT Output value
CCPDSC Binary inputs TRIP Trip signal to CB
CCRBRF Binary inputs CBALARM Alarm for faulty circuit breaker
TRBU Back-up trip by breaker failure protection function
TRBU2 Second back-up trip by breaker failure protection function
Table continues on next page
Section 2 1MRK 511 419-UUS A
DNP3 data mappings
14 650 series 2.2 ANSI
Point list manual
