Function name Signal type Signal name Description
TRRET Retrip by breaker failure protection function
TRRET_A Retrip by breaker failure protection function phase A
TRRET_B Retrip by breaker failure protection function phase B
TRRET_C Retrip by breaker failure protection function phase C
CCSSPVC Binary inputs FAIL Detection of current circuit failure
CMMXU Analog inputs IA Phase A current magnitude of reported value
IA_ANGL Phase A current magnitude angle
IB Phase B current magnitude of reported value
IB_ANGL Phase B current magnitude angle
IC Phase C current magnitude of reported value
IC_ANGL Phase C current magnitude angle
CMSQI Analog inputs 3I0 3I0 magnitude of reported value
3I0ANGL 3I0 Angle, magnitude of reported value
I1 I1magnitude of reported value
I1ANGL I1 Angle, magnitude of reported value
I2 I2 Magnitude of reported value
I2ANGL I2 Angle, magnitude of reported value
CVGAPC Analog inputs CURRENT Measured current value
VOLTAGE Measured voltage value
Binary inputs TRIP Common trip signal
TROC1 Trip signal from overcurrent function OC1
TROC2 Trip signal from overcurrent function OC2
TROV1 Trip signal from overvoltage function OV1
TROV2 Trip signal from overvoltage function OV2
TRUC1 Trip signal from undercurrent function UC1
TRUC2 Trip signal from undercurrent function UC2
TRUV1 Trip signal from undervoltage function UV1
TRUV2 Trip signal from undervoltage function UV2
CVMMXN Analog inputs F System frequency magnitude of deadband value
I Calculated current magnitude of deadband value
P Active Power magnitude of deadband value
PF Power Factor magnitude of deadband value
Q Reactive Power magnitude of deadband value
S Apparent Power magnitude of deadband value
V Calculated voltage magnitude of deadband value
Binary inputs ILAG Current is lagging voltage
ILEAD Current is leading voltage
DNPFREC Analog inputs ActSetGrp Active setting group
Ch1Ang Prefault Angle
Ch1FltAng Fault Angle
Ch1FltMag Fault Magnitude
Ch1Mag Prefault Magnitude
Ch2Ang Prefault Angle
Table continues on next page
1MRK 511 419-UUS A Section 2
DNP3 data mappings
650 series 2.2 ANSI 15
Point list manual
