1.1 Device identification Capabilities Current value If configurable, list
methods
1.1.8 Supported function
blocks
PST or LHMI
● Self Address Reservation
○ Data Sets
○ File Transfer
○ Virtual Terminal
○ Mapping to IEC 61850 Object Models defined in a DNP3
XML file
○ Function code 31, activate configuration (if checked, see
1.12)
○ Authentication (if checked, see 1.12)
1.1.9 Notable additions
1.1.10 Methods to set
configurable parameters
Software or direct PST, CMT, or LHMI
○ XML - Loaded through DNP3 File Transfer
○ XML - Loaded through other transport mechanism
○ Terminal - ASCII terminal command line
○ Software - Vendor software named
○ Proprietary file loaded through DNP3 file transfer
● Proprietary file loaded through other transport mechanism
○ Direct - Keypad on device front pane
○ Factory - Specified when device is ordered
○ Protocol - Set via DNP3 (for example assign class)
○ Other - explain
1.1.11 DNP3 XML files
available on-line
Rd Wr Filename Description of contents Not supported
○ dnpDp.xml Complete device profile
○ dnpDPCap.xml Device profile capabilities
○ dnpDPCfg.xml Device profile config values
○ ○ _____*.xml
* The Complete Device Profile Document contains the
capabilities, Current Value, and configurable methods
columns.
*
The Device Profile Capabilities contains only the
capabilities and configurable methods columns.
* The Device Profile Config. Values contains only the
Current Value column.
Table continues on next page
Section 3 1MRK 511 419-UUS A
DNP3 protocol implementation
28 650 series 2.2 ANSI
Point list manual
