1.3 IP networking Capabilities Current value If configurable, list
methods
○ Fixed at 20,000
○ Configurable, range _______ to _______
○ Configurable, selectable from ____,____,____
○ Configurable, other, describe:
1.3.13 Destination UDP port for initial unsolicited null responses (UDP only Outstations): For a UDP only Outstation, the destination UDP port
for sending initial unsolicited Null response.
○ None 20000 PST or LHMI
(UDPPortAccData)
○ Fixed at 20,000
● Configurable, range 1 to 65535
○ Configurable, selectable from ____,____,____
○ Configurable, other, describe:
1.3.14 Destination UDP port for responses (UDP only Outstations): For a UDP only Outstation, the destination UDP port for sending all
responses other than the initial unsolicited Null response.
○ None 0 PST or LHMI
(UDPPortCliMast)
○ Fixed at 20,000
● Configurable, range 0 to 65535
○ Configurable, selectable from ____,____,____
● Configurable, other, describe: If set to 0 the receiving UDP
port number will be used.
○ Use source port number
1.3.15 Multiple outstation connections (Masters only): Indicates whether multiple outstation connections are supported.
○ Supports multiple outstations (Masters only)
1.3.16 Multiple master connections (Outstations only): Outstations only. Indicates whether multiple master connections are supported and the
method that can be used to establish connections.
● Supports multiple masters (Outstations only) If supported, the
following methods may be used:
Combination of
Method 1 and
Method 2
PST or LHMI
(MasterIP-Addr and
TCPIPLisPort)
● Method 1 (based on IP address) - required
● Method 2 (based on IP port number) - recommended
○ Method 3 (browsing for static data) - optional
1.3.17 Time synchronization support:
● DNP3 LAN procedure (function code 24) LAN procedure
● DNP3 Write Time (not recommended over LAN)
○ Other, explain:
○ Not Supported
1MRK 511 419-UUS A Section 3
DNP3 protocol implementation
650 series 2.2 ANSI 35
Point list manual
