1.8 Outstation unsolicited
response support
Capabilities Current value If configurable, list methods
○ Fixed at 1 PST or LHMI
(MasterAddres)
● Configurable, range 0 to 65519
○ Configurable, selectable from ____,____,____
○ Configurable, other, describe:
1.8.3 Unsolicited response confirmation time-out: This is the amount of time that the outstation will wait for an application layer confirmation
back from the master indicating that the master received the unsolicited response message. As a minimum, the range of configurable values
must include times from one second to one minute. This parameter may be the same one that is used for normal, solicited, application
confirmation time-outs, or it may be a separate parameter.
○ Fixed at______ ms 5 seconds PST or LHMI
(tURRetryDelay)
● Configurable, range 0 to 60 seconds
○ Configurable, selectable from ___,___,___ms
○ Configurable, other, describe:
○ Variable, explain:
1.8.4 Number of Unsolicited Retries: This is the number of retries that an outstation transmits in each unsolicited response series if it does not
receive confirmation back from the master. The configured value includes identical and regenerated retry messages. One of the choices must
provide for an indefinite (and potentially infinite) number of transmissions.
● None 5 PST or LHMI
(UROfflineRetry)
○ Fixed at
● Configurable, range 0 to 10
○ Configurable, selectable from ____,____,____
○ Configurable, other, describe:
○ Always infinite, never gives up
Table 10: Outstation unsolicited response trigger conditions
1.9 Outstation unsolicited
response trigger conditions
Capabilities Current value If configurable, list methods
1.9.1 Number of class 1 events:
○ Class 1 not used to trigger Unsolicited
Responses
5 PST or LHMI
(UREvCntThold1)
○ Fixed at
● Configurable, range 1 to 100
○ Configurable, selectable from ____,____,____
○ Configurable, other, describe:
1.9.2 Number of class 2 events:
Table continues on next page
1MRK 511 419-UUS A Section 3
DNP3 protocol implementation
650 series 2.2 ANSI 43
Point list manual
