1.9 Outstation unsolicited
response trigger conditions
Capabilities Current value If configurable, list methods
○ Class 2 not used to trigger Unsolicited
Responses
5 PST or LHMI
(UREvCntThold2)
○ Fixed at
● Configurable, range 1 to 100
○ Configurable, selectable from ____,____,____
○ Configurable, other, describe:
1.9.3 Number of class 3 events:
○ Class 3 not used to trigger Unsolicited
Responses
5 PST or LHMI
(UREvCntThold3)
○ Fixed at
● Configurable, range 1 to 100
○ Configurable, selectable from ____,____,____
○ Configurable, other, describe:
1.9.4 Total number of events from any class:
● Total Number of Events not used to trigger
Unsolicited Responses
○ Fixed at
○ Configurable, range ________ to _______
○ Configurable, selectable from ____,____,____
○ Configurable, other, describe:
1.9.5 Hold time after class 1 event: A configurable value of 0 indicates that responses are not delayed due to this parameter.
○ Class 1 not used to trigger Unsolicited
Responses
5 seconds PST or LHMI
(tUREvBufTout1)
○ Fixed at ___________ ms
● Configurable, range 0 to 60 seconds
○ Configurable, selectable from ____,____,____
ms
○ Configurable, other, describe:
1.9.6 Hold time after class 2 event: A configurable value of 0 indicates that responses are not delayed due to this parameter.
○ Class 2 not used to trigger Unsolicited
Responses
5 seconds PST or LHMI
(tUREvBufTout2)
○ Fixed at ___________ ms
● Configurable, range 0 to 60 seconds
○ Configurable, selectable from ____,____,____
ms
○ Configurable, other, describe:
1.9.7 Hold time after class 3 event: A configurable value of 0 indicates that responses are not delayed due to this parameter.
Table continues on next page
Section 3 1MRK 511 419-UUS A
DNP3 protocol implementation
44 650 series 2.2 ANSI
Point list manual
