1.10 Outstation performance Capabilities Current value If configurable, list methods
1.10.7 Maximum event time-tag error for local binary and double bit I/O (ms): The error between the time-tag reported and the absolute time
of the physical event. This error includes the Internal Time Reference Error.
Note: The current value of this parameter is available remotely using protocol object Group 0 Variation 217.
○ Fixed at ___________ ms IEC T1 class
○ Range ________ to _______ ms
○ Selectable from ____,____,____ ms
● Other, describe: IEC T1 class
1.10.8 Maximum event time-tag error for local I/O other than binary and double bit data types (ms):
○ Fixed at ___________ ms IEC T1 class
○ Range ________ to _______ ms
○ Selectable from ____,____,____ ms
● Other, describe: IEC T1 class
Table 12: Individual field outstation parameters
1.11 Individual field outstation parameters Capabilities Current value If configurable, list methods
1.11.1 User-assigned location name or code string N/A
1.11.2 User-assigned ID code/number string N/A
1.11.3 User-assigned name string for the outstation N/A
1.11.4 Device Serial Number string N/A
Table 13: Security parameters
1.12 Security parameters
Capabilities Current value If configurable, list methods
1.12.1 DNP3 device support for secure authentication: The support for secure authentication is optional in DNP3 devices. Indicate here if the
device supports secure authentication. If the device does not support secure authentication, then ignore the rest of this section. If the device
does support secure authentication, then specify the version(s) that are supported in the device. The version number is an integer value
defined in the DNP3 specification. The Secure Authentication procedure defined in IEEE 1815–2010 is version 2. The Secure Authentication
procedure defined in IEEE 1815–2012 is version 5.
● Secure Authentication not supported.
If Secure Authentication is supported, what
Version(s) are supported:
Secure Authentication not
supported
○ Fixed at ___________
○ Configurable, selectable from ____,____,____
1MRK 511 419-UUS A Section 3
DNP3 protocol implementation
650 series 2.2 ANSI 47
Point list manual
