3.6 DOUBLE-BIT
BINARY INPUTS Static
(Steady-State) Group
Number: 3 Event Group
Number: 4
Capabilities
(leave tick-boxes blank if
this data type is not
supported)
Current Value
If configurable, list
methods
● Fixed at 1000
○ Configurable, range
_______ to _______
○ Configurable,
selectable from
____,____,____
○ Configurable, other,
describe:
3.7 BINARY OUTPUTS
AND BINARY OUTPUT
COMMANDS
Binary Outputs Group
Number: 10
Binary Output Events
Group Number: 11
Binary Output
Commands Group
Number: 12
Binary Output Command
Events Group Number:
13
Capabilities
(leave tick-boxes blank if
this data type is not
supported)
Current Value
If configurable, list
methods
3.7.1 Minimum pulse time allowed with Trip, Close, and Pulse On commands:
● Fixed at ______ms
(hardware may limit this
further)
5, 20 or 100 ms
○ Based on point Index.
Comment: Not shorter
than the application
thread the Automation
Bits function block is
executing in.
3.7.2 Maximum pulse time allowed with Trip, Close, and Pulse On commands:
● Fixed at 4294967296
ms (hardware may limit
this further)
4294967296 ms
○ Based on point Index
(add column to table in
part 5)
3.7.3 Binary Output Status included in Class 0 response:
Table continues on next page
1MRK 511 419-UUS A Section 3
DNP3 protocol implementation
650 series 2.2 ANSI 53
Point list manual
