Table 14: Implementation table
DNP OBJECT GROUP AND VARIATION REQUEST (Slave will parse) RESPONSE (Slave will respond with)
Object
group
number
Variation
number
Description
Function codes
(dec) Qualifier codes (hex)
Function codes
(dec)
Qualifier codes
(hex)
1 0 Binary input – any
variation
1 (read) 00, 01 (start-stop)
06 (no range, or all)
07, 08 (limited qty)
17, 27, 28 (index)
1 1
(default)
1)
Binary input – single bit
packed
1 (read) 00, 01 (start-stop)
06 (no range, or all)
07, 08 (limited qty)
17, 27, 28 (index)
129 (response)
00, 01 (start-stop)
17, 28 (index)
2)
1 2 Binary input – single bit
with flag
1 (read) 00, 01 (start-stop)
06 (no range, or all)
07, 08 (limited qty)
17, 27, 28 (index)
129 (response)
00, 01 (start-stop)
17, 28 (index)
2)
2 0 Binary input change
event – any variation
1 (read) 06 (no range, or all)
07, 08 (limited qty)
2 1 Binary input change
event without time
1 (read) 06 (no range, or all)
07, 08 (limited qty)
129 (response) 17, 28 (index)
2 1 Binary input change
event without time
130 (unsol. resp) 17, 28 (index)
2 2 Binary input change
event – with absolute
time
1 (read)
06 (no range, or all)
07, 08 (limited qty)
129 (response) 17, 28 (index)
2 2 Binary input change
event – with absolute
time
130 (unsol. resp) 17, 28 (index)
2
3
1)
Binary input change
event with relative time
1 (read) 06 (no range, or all)
07, 08 (limited qty)
129 (response) 17, 28 (index)
2 3 Binary input change
event with relative time
130 (unsol. resp) 17, 28 (index)
3 0 Double bit input – any
variation
1 (read) 00, 01 (start-stop)
06 (no range, or all)
07, 08 (limited qty)
17 ,27, 28 (index)
3
1
1)
Double bit output –
double bit packed
1 (read) 00, 01 (start-stop)
06 (no range, or all)
07, 08 (limited qty)
17, 27, 28 (index)
129 (response)
00, 01 (start-stop)
17, 28 (index)
2)
3 2 Double bit input with
flag
1 (read) 00, 01 (start-stop)
06 (no range, or all)
07, 08 (limited qty)
17, 27, 28 (index)
129 (response)
00, 01 (start-stop)
17, 28 (index)
2)
4 0 Double bit input change
event - any variation
1 (read) 06 (no range, or all)
07, 08 (limited qty)
4 1 Double bit input change
event without time
1 (read) 06 (no range, or all)
07, 08 (limited qty)
129 (response) 17, 28 (index)
Table continues on next page
