DNP OBJECT GROUP AND VARIATION REQUEST (Slave will parse) RESPONSE (Slave will respond with)
32 7 Analog input change
event — single
precision, floating point
with time
1 (read)
06 (no range, or all)
07, 08 (limited qty)
129 (response) 17, 28 (index)
32 7 Analog input change
event — single
precision, floating point
with time
130 (unsol. resp) 17, 28 (index)
32 8 Analog input change
event — double
precision, floating point
with time
1 (read)
06 (no range, or all)
07, 08 (limited qty)
129 (response) 17, 28 (index)
32 8 Analog input change
event — double
precision, floating point
with time
130 (unsol. resp) 17, 28 (index)
50
1
1)
Time and date —
absolute time
1 (read) 07, (limited qty = 1) 129 (response) 07 (limited qty = 1)
50 1 Time and date —
absolute time
2 (write) 07, (limited qty = 1)
50 3 Time and date last
absolute time at last
recorded time
2 (write)
07 (limited qty= 1)
51 1 Time and date CTO —
absolute time,
synchronized
129 (response) 07 (limited qty)
(qty = 1)
51 1 Time and date CTO —
absolute time,
synchronized
130 (unsol. resp) 07 (limited qty)
(qty = 1)
51 2 Time and date CTO —
absolute time,
unsynchronized
129 (response) 07 (limited qty)
(qty = 1)
51 2 Time and date CTO —
absolute time,
unsynchronized
130 (unsol. resp) 07 (limited qty)
(qty = 1)
52 1 Time delay coarse 129 (response) 07 (limited qty)
(qty = 1)
52 2 Time delay fine 129 (response) 07 (limited qty)
(qty = 1)
60 0 Not defined
60 1 Class objects — class 0
data
1 (read) 06 (no range, or all)
60 2 Class objects — class 1
data
1 (read) 06 (no range, or all)
07, 08 (limited qty)
60 2 Class objects — class 1
data
20 (enbl. unsol.) 06 (no range, or all)
60 2 Class objects — class 1
data
21 (disable unsol.) 06 (no range, or all)
Table continues on next page
Section 3 1MRK 511 419-UUS A
DNP3 protocol implementation
76 650 series 2.2 ANSI
Point list manual
