ABB REC670 2.1 IEC User Manual

22. Ordering for pre-congured IED
GUID-25AF8847-411F-4F1D-91ED-0ED71C5AA8A1 v8.1.1
Guidelines
Carefully read and follow the set of rules to ensure problem-free order management.
Please refer to the available functions table for included application functions.
PCM600 can be used to make changes and/or additions to the delivered factory configuration of the pre-configured.
To obtain the complete ordering code, please combine code from the tables, as given in the example below.
Example code: REC670 *2.1-A30X00- A02H02-B1A3-AC-MB-B-A3X0-DAB1RGN1N1XXXXXXX-AXFXXX-AX. Using the code of each position #1-13 specified as
REC670*1-2 2-3 3 3 3 3 3 3 3 3 3 3 3 3-4 4-5-6-7 8-9-10 10 10 10-11 11 11 11 11 11 11 11 11 11 11-12 12 12 12 12 12-13 13
# 1 - 2 - 3 - 4 - 5 6 - 7 8 - 9 -
REC670* - - - - - - -
10 - 11 - 12 - 13
- . -
Position
SOFTWARE #1 Notes and Rules
Version number
Version no
2.1
Selection for position #1.
Conguration alternatives #2 Notes and Rules
Single breaker A30
Bus coupler for double busbar A31
Double breaker B30
1 1/2 breaker diameter C30
ACT configuration
ABB standard configuration X00
Selection for position #2.
1MRK 511 361-BEN B
Bay control REC670 2.1 IEC
Product version: 2.1
106 ABB
