ABB REC670 2.1 IEC User Manual

Control and monitoring functions
GUID-E3777F16-0B76-4157-A3BF-0B6B978863DE v12.1.1
IEC 61850 ANSI Function description Bay control
REC670
REC670 (A30) REC670 (A31)
REC670 (B30)
REC670 (C30)
Control
SESRSYN 25 Synchrocheck, energizing check and synchronizing 0-6, 0-2 1 1 2 3
SMBRREC 79 Autorecloser 0-6, 0-4 1-H04 1-H04 2-H05 3-H06
APC10 3 Apparatus control for single bay, max 10 apparatuses
(1CB) incl. interlocking
1 1 1
APC15 3 Apparatus control for single bay, max 15 apparatuses
(2CBs) incl. interlocking
1 1
APC30 3 Apparatus control for up to 6 bays, max 30 apparatuses
(6CBs) incl. interlocking
1 1
QCBAY Apparatus control 1+5/APC30 1 1 1 1+5/
APC30
LOCREM Handling of LRswitch positions 1+5/APC30 1 1 1 1+5/
APC30
LOCREMCTRL LHMI control of PSTO 1+5/APC30 1 1 1 1+5/
APC30
TR1ATCC 90 Automatic voltage control for tap changer, single control 0-4 1-H11 1-H11 1-H11 2-H16
TR8ATCC 90 Automatic voltage control for tap changer, parallel
control
0-4 1-H15 1-H15 1-H15 2-H18
TCMYLTC 84 Tap changer control and supervision, 6 binary inputs 0-4 4 4 4 4
TCLYLTC 84 Tap changer control and supervision, 32 binary inputs 0-4 4 4 4 4
SLGAPC Logic rotating switch for function selection and LHMI
presentation
15 15 15 15 15
VSGAPC Selector mini switch 20 20 20 20 20
DPGAPC Generic communication function for Double Point
indication
16 16 16 16 16
SPC8GAPC Single point generic control 8 signals 5 5 5 5 5
AUTOBITS AutomationBits, command function for DNP3.0 3 3 3 3 3
SINGLECMD Single command, 16 signals 4 4 4 4 4
I103CMD Function commands for IEC 60870-5-103 1 1 1 1 1
I103GENCMD Function commands generic for IEC 60870-5-103 50 50 50 50 50
I103POSCMD IED commands with position and select for IEC
60870-5-103
50 50 50 50 50
I103POSCMDV IED direct commands with position for IEC 60870-5-103 50 50 50 50 50
I103IEDCMD IED commands for IEC 60870-5-103 1 1 1 1 1
I103USRCMD Function commands user defined for IEC 60870-5-103 4 4 4 4 4
Secondary system
supervision
CCSSPVC 87 Current circuit supervision 0-5 1 1 2 3
1MRK 511 361-BEN B
Bay control REC670 2.1 IEC
Product version: 2.1
ABB 11
