IEC 61850 ANSI Function description Bay control
REC670
REC670 (A30) REC670 (A31)
REC670 (B30)
REC670 (C30)
FUFSPVC Fuse failure supervision 0-4 3 3 3 3
VDSPVC 60 Fuse failure supervision based on voltage difference 0-2 1-G03 1-G03 1-G03 1-G03
Logic
SMPPTRC 94 Tripping logic 6 6 6 6 6
TMAGAPC Trip matrix logic 12 12 12 12 12
ALMCALH Logic for group alarm 5 5 5 5 5
WRNCALH Logic for group warning 5 5 5 5 5
INDCALH Logic for group indication 5 5 5 5 5
AND, GATE, INV,
LLD, OR,
PULSETIMER,
RSMEMORY,
SRMEMORY,
TIMERSET, XOR
Basic configurable logic blocks (see Table 2) 40-280 40-280 40-280 40-280 40-280
ANDQT,
INDCOMBSPQT,
INDEXTSPQT,
INVALIDQT,
INVERTERQT,
ORQT,
PULSETIMERQT,
RSMEMORYQT,
SRMEMORYQT,
TIMERSETQT,
XORQT
Configurable logic blocks Q/T (see Table 3) 0-1
AND, GATE, INV,
LLD, OR,
PULSETIMER,
SLGAPC,
SRMEMORY,
TIMERSET,
VSGAPC, XOR
Extension logic package (see Table 4) 0-1
FXDSIGN Fixed signal function block 1 1 1 1 1
B16I Boolean 16 to Integer conversion 18 18 18 18 18
BTIGAPC Boolean 16 to Integer conversion with Logic Node
representation
16 16 16 16 16
IB16 Integer to Boolean 16 conversion 18 18 18 18 18
ITBGAPC Integer to Boolean 16 conversion with Logic Node
representation
16 16 16 16 16
TEIGAPC Elapsed time integrator with limit transgression and
overflow supervision
12 12 12 12 12
INTCOMP Comparator for integer inputs 12 12 12 12 12
REALCOMP Comparator for real inputs 12 12 12 12 12
Monitoring
1MRK 511 361-BEN B
Bay control REC670 2.1 IEC
Product version: 2.1
12 ABB
