IEC 61850 ANSI Function description Bay control
REC670
(Customized)
REC670 (A30)
REC670 (A31)
REC670 (B30)
REC670 (C30)
FRONT, LANABI,
LANAB, LANCDI,
LANCD
Ethernet configuration of links 1 1 1 1 1
GATEWAY Ethernet configuration of link one 1 1 1 1 1
OPTICAL103 IEC 60870-5-103 Optical serial
communication
1 1 1 1 1
RS485103 IEC 60870-5-103 serial communication for
RS485
1 1 1 1 1
AGSAL Generic security application component 1 1 1 1 1
LD0LLN0 IEC 61850 LD0 LLN0 1 1 1 1 1
SYSLLN0 IEC 61850 SYS LLN0 1 1 1 1 1
LPHD Physical device information 1 1 1 1 1
PCMACCS IED Configuration Protocol 1 1 1 1 1
SECALARM Component for mapping security events on
protocols such as DNP3 and IEC103
1 1 1 1 1
FSTACCS
FSTACCSNA
Field service tool access via SPA protocol
over ethernet communication
1 1 1 1 1
ACTIVLOG Activity logging parameters 1 1 1 1 1
ALTRK Service Tracking 1 1 1 1 1
SINGLELCCH Single ethernet port link status 1 1 1 1 1
PRPSTATUS Dual ethernet port link status 1 1 1 1 1
Process bus communication IEC 61850-9-2
1)
PRP IEC 62439-3 parallel redundancy protocol 0-1 1-P03 1-P03 1-P03 1-P03
Remote communication
Binary signal transfer receive/transmit 6/36 6/36 6/36 6/36 6/36
Transmission of analog data from LDCM 1 1 1 1 1
Receive binary status from remote LDCM 6/3/3 6/3/3 6/3/3 6/3/3 6/3/3
Scheme communication
ZCPSCH 85 Scheme communication logic for distance or
overcurrent protection
0-1 1-K01 1-K01 1-K01 1-K01
ZCRWPSCH 85 Current reversal and weak-end infeed logic
for distance protection
0-1 1-K01 1-K01 1-K01 1-K01
ZCLCPSCH Local acceleration logic 0-1 1-K01 1-K01 1-K01 1-K01
ECPSCH 85 Scheme communication logic for residual
overcurrent protection
0-1 1-C51 1-C51 1-C52 1-C53
ECRWPSCH 85 Current reversal and weak-end infeed logic
for residual overcurrent protection
0-1 1-C51 1-C51 1-C52 1-C53
1) Only included for 9-2LE products
1MRK 511 361-BEN B
Bay control REC670 2.1 IEC
Product version: 2.1
16 ABB
