ABB REC670 2.1 IEC User Manual

Communication
GUID-5F144B53-B9A7-4173-80CF-CD4C84579CB5 v12
IEC 61850 ANSI Function description Bay control
REC670
(Customized)
REC670 (A30) REC670 (A31)
REC670 (B30)
REC670 (C30)
Station communication
LONSPA, SPA SPA communication protocol 1 1 1 1 1
ADE LON communication protocol 1 1 1 1 1
HORZCOMM Network variables via LON 1 1 1 1 1
PROTOCOL Operation selection between SPA and IEC
60870-5-103 for SLM
1 1 1 1 1
RS485PROT Operation selection for RS485 1 1 1 1 1
RS485GEN RS485 1 1 1 1 1
DNPGEN DNP3.0 communication general protocol 1 1 1 1 1
DNPGENTCP DNP3.0 communication general TCP
protocol
1 1 1 1 1
CHSERRS485 DNP3.0 for EIA-485 communication protocol 1 1 1 1 1
CH1TCP, CH2TCP,
CH3TCP, CH4TCP
DNP3.0 for TCP/IP communication protocol 1 1 1 1 1
CHSEROPT DNP3.0 for TCP/IP and EIA-485
communication protocol
1 1 1 1 1
MST1TCP,
MST2TCP,
MST3TCP,
MST4TCP
DNP3.0 for serial communication protocol 1 1 1 1 1
DNPFREC DNP3.0 fault records for TCP/IP and EIA-485
communication protocol
1 1 1 1 1
IEC 61850-8-1 Parameter setting function for IEC 61850 1 1 1 1 1
GOOSEINTLKRCV Horizontal communication via GOOSE for
interlocking
59 59 59 59 59
GOOSEBINRCV GOOSE binary receive 16 16 16 16 16
GOOSEDPRCV GOOSE function block to receive a double
point value
64 64 64 64 64
GOOSEINTRCV GOOSE function block to receive an integer
value
32 32 32 32 32
GOOSEMVRCV GOOSE function block to receive a
measurand value
60 60 60 60 60
GOOSESPRCV GOOSE function block to receive a single
point value
64 64 64 64 64
GOOSEVCTRRCV Horizontal communication via GOOSE for
VCTR
7 7 7 7 7
GOOSEVCTRCONF GOOSE VCTR configuration for send and
receive
1 1 1 1 1
MULTICMDRCV,
MULTICMDSND
Multiple command and transmit 60/10 60/10 60/10 60/10 60/10
1MRK 511 361-BEN B
Bay control REC670 2.1 IEC
Product version: 2.1
ABB 15
