IEC 61850 ANSI Function description Bay control
REC670
REC670 (A30) REC670 (A31)
REC670 (B30)
REC670 (C30)
CVMMXN,
VMMXU, CMSQI,
VMSQI, VNMMXU
Measurements 6 6 6 6 6
CMMXU Measurements 10 10 10 10 10
AISVBAS Function block for service value presentation of
secondary analog inputs
1 1 1 1 1
EVENT Event function 20 20 20 20 20
DRPRDRE,
A1RADR-
A4RADR,
B1RBDR-
B22RBDR
Disturbance report 1 1 1 1 1
SPGAPC Generic communication function for Single Point
indication
64 64 64 64 64
SP16GAPC Generic communication function for Single Point
indication 16 inputs
24 24 24 24 24
MVGAPC Generic communication function for Measured Value 24 24 24 24 24
BINSTATREP Logical signal status report 3 3 3 3 3
RANGE_XP Measured value expander block 66 66 66 66 66
SSIMG 63 Gas medium supervision 21 21 21 21 21
SSIML 71 Liquid medium supervision 3 3 3 3 3
SSCBR Circuit breaker monitoring 0-18 3-M13 3-M13 6-M15 9-M17
LMBRFLO Fault locator 0-1 1-M01 1-M01 1-M01 1-M01
I103MEAS Measurands for IEC 60870-5-103 1 1 1 1 1
I103MEASUSR Measurands user defined signals for IEC 60870-5-103 3 3 3 3 3
I103AR Function status auto-recloser for IEC 60870-5-103 1 1 1 1 1
I103EF Function status earth-fault for IEC 60870-5-103 1 1 1 1 1
I103FLTPROT Function status fault protection for IEC 60870-5-103 1 1 1 1 1
I103IED IED status for IEC 60870-5-103 1 1 1 1 1
I103SUPERV Supervison status for IEC 60870-5-103 1 1 1 1 1
I103USRDEF Status for user defined signals for IEC 60870-5-103 20 20 20 20 20
L4UFCNT Event counter with limit supervision 30 30 30 30 30
TEILGAPC Running hour-meter 6 6 6 6 6
Metering
PCFCNT Pulse-counter logic 16 16 16 16 16
ETPMMTR Function for energy calculation and demand handling 6 6 6 6 6
1MRK 511 361-BEN B
Bay control REC670 2.1 IEC
Product version: 2.1
ABB 13
