ABB REC670 2.1 IEC User Manual

External resistor unit
SEMOD120228-4 v7
High impedance resistor unit 1-ph with resistor and voltage dependent resistor for
20-100V operating voltage Quantity:
1 2 3
RK 795 101-MA
High impedance resistor unit 3-ph with resistor and voltage dependent resistor for
20-100V operating voltage
Quantity: RK 795 101-MB
High impedance resistor unit 1-ph with resistor and voltage dependent resistor for
100-400V operating voltage Quantity:
1 2 3
RK 795 101-CB
High impedance resistor unit 3-ph with resistor and voltage dependent resistor for
100-400V operating voltage
Quantity: RK 795 101-DC
Combiex
IP15161-1 v1
Key switch for settings
SEMOD130356-4 v5
Key switch for lock-out of settings via LCD-HMI Quantity: 1MRK 000 611-A
Note: To connect the key switch, leads with 10 A Combiflex socket on one end must be used.
SEMOD130267-5 v6
Mounting kit Ordering number
Side-by-side mounting kit Quantity: 1MRK 002 420-Z
Conguration and monitoring tools
IP15162-1 v2
M15042-3 v3
Front connection cable between LCD-HMI and PC Quantity: 1MRK 001 665-CA
SEMOD131414-4 v3
LED Label special paper A4, 1 pc Quantity: 1MRK 002 038-CA
LED Label special paper Letter, 1 pc Quantity: 1MRK 002 038-DA
Manuals
M15161-3 v11
Note: One (1) IED Connect CD containing user documentation (Operation manual, Technical manual,
Installation manual, Commissioning manual, Application manual and Getting started guide), Connectivity
packages and LED label template is always included for each IED.
Rule: Specify additional quantity of IED Connect CD requested
. Quantity: 1MRK 002 290-AD
1MRK 511 361-BEN B
Bay control REC670 2.1 IEC
Product version: 2.1
112 ABB
