M13765-1 v4
Table 114. Indications
Function Value
Buffer capacity Maximum number of indications presented for single disturbance 96
Maximum number of recorded disturbances 100
M12702-1 v4
Table 115. Event recorder
Function Value
Buffer capacity Maximum number of events in disturbance report 150
Maximum number of disturbance reports 100
Resolution 1 ms
Accuracy Depending on time
synchronizing
M13747-1 v5
Table 116. Trip value recorder
Function Value
Buffer capacity Maximum number of analog inputs 30
Maximum number of disturbance reports 100
M12384-1 v6.1.1
Table 117. Disturbance recorder
Function Value
Buffer capacity Maximum number of analog inputs 40
Maximum number of binary inputs 352
Maximum number of disturbance reports 100
Maximum total recording time (3.4 s recording time and maximum number
of channels, typical value)
340 seconds (100 recordings) at 50 Hz
280 seconds (80 recordings) at 60 Hz
GUID-C43B8654-60FE-4E20-8328-754C238F4AD0 v2
Table 118. Limit counter L4UFCNT
Function Range or value Accuracy
Counter value 0-65535 -
Max. count up speed 30 pulses/s (50% duty cycle) -
1MRK 511 361-BEN B
Bay control REC670 2.1 IEC
Product version: 2.1
ABB 83
