ABB REF 54 Series Technical Reference Manual

114
1MRS750527-MUM
)HHGHU7HUPLQDO
Technical Reference Manual, General
5()B
&RPPDQGV
Explanations to the Table 12.6.-2:
6W
Status
A According to the IEC 60870-5-103 standard
B According to “Digitale Stationsleittechnik - Ergänzende Empfehlungen zur
Anwendung in Verteilnetzstationen”
P Private definition
)W\S
Function type
Note: If stated as *), the signal type Ftyp corresponds with the unit function
type. Unit function type may be adjusted via the “Function type” parameter.
,QI1XP
Information element number
&27FPG
Cause of transmission values in command direction
20 General command
&27UHVS
Cause of transmission values in response direction
20 Positive acknowledgement
21 Negative acknowledgement
7DEOH&RPPDQGV
&RPPDQGV 6W )W\S
,QI
1XP
7\S
&27
FPG
&27
UHVS
COCB1 Circuit breaker B 240 160 20 20 20,21
COCB2 Circuit breaker P 242 207 20 20 20,21
CODC1 Disconnector P 243 206 20 20 20,21
CODC2 Disconnector P 253 37 20 20 20,21
CODC3 Disconnector P 253 44 20 20 20,21
CODC4 Disconnector P 253 51 20 20 20,21
CODC5 Disconnector P 253 58 20 20 20,21
CO3DC1 Disconnector P 253 17 20 20 20,21
CO3DC1 Disconnector Earth P 253 18 20 20 20,21
CO3DC2 Disconnector P 253 19 20 20 20,21
CO3DC2 Disconnector Earth P 253 28 20 20 20,21
COSW1 On / Off switch 1 P 253 79 20 20 20,21
COSW2 On / Off switch 2 P 253 80 20 20 20,21
COSW3 On / Off switch 3 P 253 81 20 20 20,21
COSW4 On / Off switch 4 P 253 82 20 20 20,21
