Page #115 background image
1MRS750527-MUM
)HHGHU7HUPLQDO
Technical Reference Manual, General
5()B
115
&ODVVPHDVXUDQGVHWV
Explanations to the Table 12.6.-3:
57'IUDPHLIFDUGLQVWDOOHGDQGIUDPHVHOHFWHG
*) According to the device function type.
**) Selected by RTD data frame parameter. Nominal valuess are according to the RTD input signal type
and the range parameters mentioned in the Technical Reference Manual rounded to the nearest integer
(e.g. 2.5 = 3). Store and reset is needed after adjusting the RTD input signal type and range parameters,
in case of new nominal values are wanted in IEC_103.
6HW1R
Class 2 measurand set No (1...11)
6W
A According to the IEC 60870-5-103 standard
P Private definition
)XQF7\SH
,QIR1XP
Class 2 Frame identification
Note: If stated as *), the signal type Ftyp corresponds with the unit function
type. Unit function type may be adjusted via the Function type parameter.
1XPGDWD
The number of the data values in the class 2 message data part
7\S
Meas type 3 or 9 (when the definition is private, meas type 9 is used)
'DWD
Measurement data in class 2 message data part:
Not available: -
7DEOH5HFRPPHQGHG&ODVVPHDVXUDQGVHWV
6HW
1R
6W )XQFW\S
,QIR
1XP
1XP
GDWD
7\S 'DWD
1 Meas I: 144 A *) 144 1 3 IL2
2 Meas I: 145 A *) 145 2 3 IL2, U12
3 Meas I: 146 A *) 146 4 3 IL1, U12, P, Q
4 Meas I: 147 A *) 147 2 3 Io, Uo
5 Meas II: 148 A *) 148 9 9 IL1, IL2, IL3, U1, U2, U3, P, Q, f
6 Meas II: ABB1 P 134 137 16 9 IL1, IL2, IL3, Io, -, -, -, U12, U23, U31, P, Q, f, -, -,
PF
7 Meas II: ABB2 P 134 137 16 9 IL1, IL2, IL3, Io, U1, U2, U3, -, -, -, P, Q, f, -, -, PF
8 Meas II: ABB3 P 135 137 12 9 IL1, IL2, IL3, U1, U2, U3, Io, Uo, P, Q, PF, f
9 Meas II: ABB4 P 135 138 12 9 IL1, IL2, IL3, U12, U23, U31, Io, Uo, P, Q, PF, f
10 Meas II: ABB5 P 135 139 4 9 IL1, IL2, IL3, Io
11 Meas II: ABB6 P 135 140 5 9 IL1, IL2, IL3, Io, Uo
12 Meas II: ABB7 P 136 141 14 9 IL1, IL2, IL3, IL1B, IL2B, IL3B, U1, I0, U0, I0B, P,
Q, PF, f
13 Meas II: ABB8 P 136 142 14 9 IL1, IL2, IL3, IL1B, IL2B, IL3B, U12, I0, I0B, U0,
P, Q, PF, f
14 Meas II: ABB9 P 136 143 15 9 IL1, IL2, IL3, U12, U23, U31, U1b, I0, I0B, U0,
U0B, P, Q, PF, f
15 Meas II: ABB10 P 136 144 15 9 IL1, IL2, IL3, U1, U2, U3, U12B, I0, IOB, U0,
U0B, P, Q, PF, f
16 Meas II: ABB11 P 136 145 20 9 IL1, IL2, IL3, IL1B, IL2B, IL3B, U1, U2, U3, U1B,
U2B, U3B, I0, I0B, U0, U0B, P, Q, PF, f
17 Meas II: ABB12 P 136 146 20 9 IL1, IL2, IL3, IL1B, IL2B, IL3B, U12, U23, U31,
U12B, U23B, U31B, Io, IoB, Uo, UoB, P, Q, PF, f
RTD**
)
P 136 147 8 9 RTD1, RTD2, RTD3, RTD4, RTD5, RTD6, RTD7,
RTD8
