ABB REF 542plus Technical Reference Manual

53
Table 7.-5 Analog I/O modules
NUMBER CODE NAME DESCRIPTION
N none No analog input or output Empty analog I/O module slot
A 750211/801 Analog input module 4-
20 mA
Analog input module for 4-20 mA
installed, up to 6 inputs
B 750237/801 Analog output module 0
(4)-20 mA
Analog output module for 0(4)-20 mA
installed, up to 4 outputs
76B6A3 33036SZ41
Table 7.-6 Binary I/O modules
NUMBER CODE NAME DESCRIPTION
1 701952/801 Static I/O Application in GIS panel with coil
supervision through a control
continuity check
2 701952/802 Static I/O - without
control continuity check
Static I/O without control continuity
check
5 750132/801 Binary I/O3 - 19-72 V/14
V DC, standard
Standard version with a 14 V DC
threshold value for an application in
an auxiliary circuit with a DC voltage
range of 19-72 V DC
6 750132/803 Binary I/O3 - 19-72 V/14
V DC, with static
channel
As no. 5 + one static output channel
for energy metering
7 750161/801 Binary I/O3 - 19-72 V/14
V DC, interconnected
input, standard
As no. 5 + interconnected binary
inputs
8 750161/803 Binary I/O3 - 19-72 V/14
V DC, interconnected
input, with static channel
As no. 5 + interconnected binary
inputs + one static output channel for
energy metering
9 750132/802 Binary I/O3 - 88-132 V/
50 V DC, standard
Standard version with a 50V DC
threshold value for an application in
an auxiliary circuit with a DC voltage
range of 88-132 V DC
A 750132/804 Binary I/O3 - 88-132 V/
50 V DC, with static
channel
As no. 9 + one static output channel
for energy metering
B 750161/802 Binary I/O3 - 88-132 V/
50 V DC, interconnected
input, standard
As no. 9 + interconnected binary
inputs
C 750161/804 Binary I/O3 - 88-132 V/
50 V DC, interconnected
input, with static channel
As no. 9 + interconnected binary
inputs + one static output channel for
energy metering
D 750132/805 Binary I/O3 - 88-132 V/
72 V DC, standard
Standard version with a 72 V DC
threshold value for an application in
an auxiliary circuit with a DC voltage
range of 88-132 V DC
Multifunction Protection and Switchbay Control
Unit
Technical Reference Manual
REF 542plusREF 542plus
1MRS755859
