4.2.1.3. How to monitor recorded data
The contents of the event register and the information on number of auto-reclosures
initiated, pickups and trips are found under the main menu group RECORDED
DATA.
1. Press an arrow button to access the main menu.
2. Use
or to select RECORDED DATA in the main menu and press to enter
the first event.
3. To navigate between the events, use
and .
4. To enter a submenu, use
and to exit, use .
5. To return the display to the idle mode, press
.
NUMBER OF 79
Main Menu
Group Menu
Parameter Menus
SETTINGS
CONFIGURATION
MEASUREMENTS
RECORDED DATA
NUMBER OF PICKUPS
5. EVENT
4. EVENT
3. EVENT
RECORDED DATA
1. EVENT
2. EVENT
RECORDED DATA
RECORDED DATA
RECORDED DATA
INFO
1. la CT:x.xx
1. lb CT:x.xx
1. lc CT:x.xx
1.50P-1 DUR%:x.xx
1. 51P DUR%:x.xx
1. ln CT%:x.x
1. 51N DUR%:x.xx
1. HH.MM:SS.SSS
1. YY-MM-DD
51P TRIP : x
PICKUP 51P PU :x
50P-2 PU :x
51N PU :x
50N PU :x
50P-1 PU :x
OPERATION
NUMBER OF TRIPS
1. la pu CT:0.00
1. lb pu CT:0.00
1. lc pu CT:0.00
1. ln pu CT:0.00
46 PU :x
50P-1 TRIP : x
50P-2 TRIP : x
OTHER TRIP : x
RECORDED DATA
SHOT 1 50P-1 : xxx
SHOT 1 Ext : xxx
SHOT 1 51P : xxx
SHOT 1 51N : xxx
SHOT 2 50P-1 : xxx
SHOT 2 Ext : xxx
SHOT 2 51P : xxx
SHOT 2 51N : xxx
SHOT 3 50P-1 : xxx
SHOT 3 Ext : xxx
SHOT 3 51P : xxx
SHOT 3 51N : xxx
1.50P-2 DUR%:x.xx
1. 50N DUR%:x.xx
1. l (unbal) %:x.xx
1. 46 DUR%:x.xx
1. TH PU %:x.xx
1. TH TR %:x.xx
1. ExtTR DUR%:x.xx
1. TR nr 79 :x.xx
1. Arc L DUR%:x.xx
1. Arc R DUR%:x.xx
A070067
Fig. 4.2.1.3.-1 Monitoring recorded data
