22. Selection and
ordering data
The IED type and serial number label
identifies the protection and control IED. The
label placed is on the side of the IED case.
The IED labels include a set of smaller size
labels, one label for each module in the IED.
The module labels state the type and serial
number of each module.
The order number consists of a string of
codes generated from the hardware and
software modules of the IED. Use the
ordering key information in tables to
generate the order number when ordering
protection and control IEDs.
S B F B A B A C B B B Z A Z N A X A
# DESCRIPTION
1
IED
630 series IED, 4U half 19” housing
S
2 Standard
IEC
B
3 Main application
Feeder protection and control
F
GUID-3C2FC288-F60C-4ED6-BA44-55A183AB8514 V1 EN
Feeder Protection and Control 1MRS756380 A
REF630
Product version: 1.0 Issued: 15.09.2009
