Table 105. Functions included in REF630, continued
Functionality IEC 61850 IEC 60617 ANSI
Measured value limit supervision MVEXP
Station battery supervision SPVNZBAT U<> U<>
Energy monitoring EPDMMTR E E
Measurement
Three-phase current CMMXU 3I 3I
Three-phase voltage, phase-to-earth
voltages (RMS)
VPHMMXU 3Upe 3Upe
Three-phase voltage, phase-to-phase
voltages (RMS)
VPPMMXU 3Upp 3Upp
Residual current RESCMMXU I
0
I
0
Residual voltage RESVMMXU U
0
V
n
Sequence current CSMSQI I
1
,I
2
I
1
,I
2
Sequence voltage VSMSQI U
1
,U
2
V
1
,V
2
Power monitoring with P, Q, S, power
factor, frequency
PWRMMXU PQf PQf
Metering
Pulse counter for energy metering PCGGIO
Disturbance recorder function
Disturbance recorder DRRDRE DREC DREC
Analog channels 1-10 (samples) A1RADR ACH1 ACH1
Analog channel 11-20 (samples) A2RADR ACH2 ACH2
Analog channel 21-30 (samples) A3RADR ACH3 ACH3
Analog channel 31-40 (calc. val.) A4RADR ACH4 ACH4
Binary channel 1-16 B1RBDR BCH1 BCH1
Binary channel 17-32 B2RBDR BCH2 BCH2
Binary channel 33-48 B3RBDR BCH3 BCH3
Binary channel 49-64 B4RBDR BCH4 BCH4
