ABB RER615 Modbus Point List Manual

2.4.40 Control structure 5
Table 131: Control structure 5
RegA Type Scale IEC 61850 name SA name Description Values
8021 Execute register 1
8022 Password reg 1 acc to setting
8023 Password reg 2 acc to setting
8024 Control register < single bit >
8025 Confirm register < single bit >
2.4.41 Control structure 6
Table 132: Control structure 6
RegA Type Scale IEC 61850 name SA name Description Values
8026 Execute register 1
8027 Password reg 1 acc to setting
8028 Password reg 2 acc to setting
8029 Control register < single bit >
8030 Confirm register < single bit >
2.4.42 Control structure 7
Table 133: Control structure 7
RegA
Type Scale IEC 61850 name SA name Description Values
8031 Execute register 1
8032 Password reg 1 acc to setting
8033 Password reg 2 acc to setting
8034 Control register < single bit >
8035 Confirm register < single bit >
2.4.43 Control structure 8
Table 134: Control structure 8
RegA
Type Scale IEC 61850 name SA name Description Values
8036 Execute register 1
8037 Password reg 1 acc to setting
8038 Password reg 2 acc to setting
8039 Control register < single bit >
8040 Confirm register < single bit >
Section 2 1MRS757822 B
Modbus data mappings
70 Recloser Protection and Control RER615
Point List Manual
