ABB | SACE Emax 2
Identification of alarms or failures | 9 - Accessories297 | © 2017 ABB | 1SDH001330R0002 - ECN000058721 Rev. A
Continued from the previous page
Faults Possible causes Suggestions
It is not possible to remove
the circuit-breaker from the
disconnected position
Fail Safe lock active
Discharge the closing springs of the
command
Tripping times shorter than
expected
Selected threshold too low Modify the threshold
Wrong curve selected Modify the curve
Thermal memory enabled Disable it if it is not necessary
Incorrect neutral selection Modify the neutral selection
Zone Selectivity enabled Disable it if it is not necessary
Tripping times longer than
expected
Threshold too high Modify the threshold
Curve too high Modify the curve
Wrong curve selected Modify the curve type
Incorrect neutral selection Modify the neutral selection
Rapid trip with I3 = Off linst trip
Correct operating condition with
short circuit at high current
High ground-fault current, but
no trip occurs
Incorrect selection of the sensor Set internal or external sensor
Function G inhibited owing to high
current
Correct operating condition (see
use cases in the chapter that
describes the protection)
Display off (if present)
No auxiliary power supply and the
current and/or voltage is less than
minimum value
Correct operating condition.
Temperature outside range Correct operating condition.
The display is not backlit (if
present)
Current and/or voltages below the
display switch-on limit
Correct operating condition.
Incorrect current reading
Current below the minimum
threshold that can be displayed
Correct operating condition.
Incorrect voltage, power and
cos φ reading
Incorrect connection between
isolation transformer and Ekip
Measuring
Check the connections between
the isolation transformer and Ekip
Measuring
Voltage parameter setting error Set the correct parameters
The expected trip does not
occur
Trip excluded
Correct operating condition. Enable
trip if necessary
No activation of the Voltage
unbalance protection (VU)
Values outside range Correct operating condition.
Opening data not displayed
No auxiliary power supply and/or
battery low
Correct operating condition.
The password is not
requested
The password was disabled or
already inserted recently
Correct operating condition, reset
the password with a value other than
“00000”
Communication problems
with Ekip Com, Ekip Link or
Ekip Signalling
Circuit-breaker in withdrawn
position, Vaux absent or modules
not inserted properly
Insert modules, set circuit-breaker to
Connected position, connect Vaux
State of CB Position field not
aligned with circuit-breaker
position
Absence of Ekip Com or Ekip Link
modules, or contact S75I
Check for presence of Ekip Com
or Ekip Link modules and connect
contact S75/I
