20
Code Event No. represent- Factory
ing the event setting
E25 Output signal SS1 activated 1 1
E26 Output signal SS1 reset 2 0
E27 Output signal SS2 activated 4 1
E28 Output signal SS2 reset 8 0
E29 Output signal SS3 activated 16 1
E30 Output signal SS3 reset 32 0
E31 Output signal SS4 activated 64 1
E32 Output signal SS4 reset 128 0
Event mask V157, factory setting 85
E33 Output signal TS1 activated 1 1
E34 Output signal TS1 reset 2 0
E35 Output signal TS2 activated 4 1
E36 Output signal TS2 reset 8 0
E37 Output signal TS3 activated 16 1
E38 Output signal TS3 reset 32 0
E39 Output signal TS4 activated 64 1
E40 Output signal TS4 reset 128 0
Event mask V158, factory setting 85
E41 Recovery function in progress 1 1
E42 Recovery function stops 2 1
E43 Recovery function interrupted 4 0
E44 Recovery function output operates 8 1
E45 Recovery function output resets 16 0
Event mask V159, factory setting 11
E50 Restart of microprocessor * -
E51 Overflow of event register * -
E52 Temporary disturbance in data communication * -
E53 No response from the module over the data * -
communication
E54 Module responds again over the data communication * -
Explanation
0 Not included in event reporting
1 Included in event reporting
* No code number, always communicated
- cannot be programmed
The codes E50...E54 and the events represented
by these cannot be excluded from event report-
ing.
The event codes E52...E54 are generated by a
control data communicator (for instance SRIO
1000M)
