19
Serial
communication
parameters
Event codes
Event codes have been defined for starting and
tripping of the separate protection stages and
for the output signal states. The event codes can
be transmitted to higher system levels over the
serial bus. An event to be communicated is
marked with the factor 1. An event mask is
formed by adding the weighting factors of the
events communicated.
Event mask Codes Setting range Factory setting
V153 E1...E6 0...63 21
V154 E7...E12 0...63 21
V155 E13...E18 0...63 21
V156 E19...E24 0...63 21
V157 E25...E32 0...255 85
V158 E33...E40 0...255 85
V159 E41...E45 0...31 11
Event codes of protection relay module SPCF 1D15:
Code Event No. represent- Factory
ing the event setting
E1 Starting of stage 1 1 1
E2 Resetting of stage 1 2 0
E3 Tripping of stage 1, timer 1 4 1
E4 Tripping of stage 1 (timer 1) reset 8 0
E5 Tripping of stage 1, timer 2 16 1
E6 Tripping of stage 1 (timer 2) reset 32 0
Event mask V153, factory setting 21
E7 Starting of stage 2 1 1
E8 Resetting of stage 2 2 0
E9 Tripping of stage 2, timer 1 4 1
E10 Tripping of stage 2 (timer 1) reset 8 0
E11 Tripping of stage 2, timer 2 16 1
E12 Tripping of stage 2 (timer 2) reset 32 0
Event mask V154, factory setting 21
E13 Starting of stage 3 1 1
E14 Resetting of stage 3 2 0
E15 Tripping of stage 3, timer 1 4 1
E16 Tripping of stage 3 (timer 1) reset 8 0
E17 Tripping of stage 3, timer 2 16 1
E18 Tripping of stage 3 (timer 2) reset 32 0
Event mask V155, factory setting 21
E19 Starting of stage 4 1 1
E20 Resetting of stage 4 2 0
E21 Tripping of stage 4, timer 1 4 1
E22 Tripping of stage 4 (timer 1) reset 8 0
E23 Tripping of stage 4, timer 2 16 1
E24 Tripping of stage 4 (timer 2) reset 32 0
Event mask V156, factory setting 21
