ABB TPL-C Series User Manual

Operation Manual / TPL67-C.. - TPL71-C..
Spare parts
12
View of turbine cleaning system with
part numbers (optional)
12.3
Page 125
© Copyright 2016 ABB. All rights reserved.
April 2016 HZTL2488_EN Revision C
Radial gas inlet casing
Part number
Description
51229 Cleaning pipe
52249
Holder complete
51255 (in spare parts set) Locking plate
52200 (in spare part set)
Gasket
52204 (in spare part set) Hexagon-head screw
52205 (in spare part set)
Hexagon-head screw
52208 (in spare part set) Nozzle
52209 (in spare part set)
Nozzle
52210 (in spare part set) Nozzle
52213 (in spare part set)
Locking plate
52219 (in spare part set) Hollow screw
52257 (in spare part set)
Hexagon-head screw
52258 (in spare part set) Verbus Ripp® washer
