3 Weight and transportation of the
turbocharger
Lifting gear with a sufficient load limit must be used for installing the turbocharger. The fol-
lowing weight specification applies to the heaviest variant possible. Depending on the spe-
cification, the weight specified on the rating plate may be lower than the standard value
specified here.
u Remove insulation jacket and insulation at gas inlet casing.
Weights [kg]
TPL67-C TPL71-C
1330 2040
Table4
Weights [kg]
TPL67VC32
1330
Table5
