4 Installing the turbocharger
The TPL-C turbocharger has a two-part foot, consisting of a foot at the turbine end (TE) and
a foot at the compressor end (CE). The foot at the compressor end (CE) is rigidly attached to
the engine support, whereas the foot at the turbine end (TE) is a sliding foot that is pressed
onto the engine support to compensate for thermal expansion during operation.
u Lift the turbocharger as described in the chapter Weight and Transport, place onto the
bracket and align.
u Secure the turbocharger as described in steps 1-10.
TE Foot on turbine end
CE Foot on compressor end
A Foot contact surface
M Centre axis
Table6
