ABB TPL-C Series User Manual

Operation Manual / TPL67-C.. - TPL71-C..
Preliminary remarks
1
Layout and function
1.2
Page 6
© Copyright 2016 ABB. All rights reserved.
April 2016 HZTL2488_EN Revision C
Layout and function
1.2
01
Filter silencer 08 Nozzle ring
02
Radial plain bearing 09 Turbine wheel
03
Thrust bearing 10 Bearing casing
04
Bearing bush 11 Diffuser
05
Radial plain bearing 12 Compressor wheel
06
Gas outlet casing 13 Compressor casing
07
Gas inlet casing
1.2
TPL67/71-C
