7 Removal and installation
7.1 Turbocharger weights
Lifting gear with a sufficient load limit must be used for removing and
installing the turbocharger. The following weight specification is the
heaviest variant possible. This standard value may deviate from the data
on the rating plate depending on the specification.
Weights [kg]
TPL69-A TPL73-A TPL77-A
1780 3070 4840
