TPU2000/2000R Modbus/Modbus Plus Automation Guide
281
4.5 Transmit Programmable Output Select ( 3 4 5 )
Bit = 0, Physical Output is selected.
Bit = 1, Physical Output is not selected.
Least significant low byte consists of bits 0 through 7.
Least significant high byte consists of bits 8 through 15.
Most significant low byte consists of bits 16 through 23.
Most significant high byte consists of bits 24 through 31.
Bit
Logical Output
0 Not used, reserved for fixed Differential Trip
1 OUTPUT1
2 OUTPUT2
3 OUTPUT3
.
.
.
30 OUTPUT30
31 OUTPUT31
Msg byte
Definition
1/1 Relay Status (see command 3 4 1, msg 1/1)
1/2 Command + Subcommand = 0x45
1/3 Total Number of Messages = 21
2/1 Contact OUT5 most significant high byte
2/2 Contact OUT5 most significant low byte
2/3 Contact OUT5 least significant high byte
3/1 Contact OUT5 least significant low byte
3/2 Contact OUT7 most significant high byte
3/3 Contact OUT7 most significant low byte
4/1 Contact OUT7 least significant high byte
4/2 Contact OUT7 least significant low byte
4/3 Contact OUT4 most significant high byte
5/1 Contact OUT4 most significant low byte
5/2 Contact OUT4 least significant high byte
5/3 Contact OUT4 least significant low byte
6/1 Contact OUT6 most significant high byte
6/2 Contact OUT6 most significant low byte
6/3 Contact OUT6 least significant high byte
7/1 Contact OUT6 least significant low byte
7/2 Contact OUT3 most significant high byte
7/3 Contact OUT3 most significant low byte
8/1 Contact OUT3 least significant high byte
8/2 Contact OUT3 least significant low byte
8/3 Contact OUT2 most significant high byte
9/1 Contact OUT2 most significant low byte
9/2 Contact OUT2 least significant high byte
9/3 Contact OUT2 least significant low byte
10/1 Contact OUT1 most significant high byte
10/2 Contact OUT1 most significant low byte
10/3 Contact OUT1 least significant high byte
11/1 Contact OUT1 least significant low byte
11/2-21/1 Spare Outputs
21/2 Checksum high byte
21/3 Checksum low byte
