TPU2000/2000R Modbus/Modbus Plus Automation Guide
295
4/1 Ib (low byte)
4/2 Ic (high byte)
4/3 Ic (mid byte)
5/1 Ic (low byte)
5/2 In/Ig (high byte)
5/3 In/Ig (mid byte)
6/1 In/Ig (low byte)
6/2 Spare
6/3 Spare
5.6 Show Average Load Current ( 3 5 6 )
Msg byte
Definition
1/1 Relay Status (see command 3 4 1, msg 1/1)
1/2 Command + Subcommand = 0x56
1/3 Total Number of Messages = 3
2/1 Aux. Status byte (see command 3 5 1, msg 2/1)
2/2 Iavg (high byte)
2/3 Iavg (mid byte)
3/1 Iavg (low byte)
3/2 Spare
3/3 Spare
5.7 Show Wdg 1 & 2 Differential Metering ( 3 5 7 )
Msg byte
Definition
1/1 Relay Status (see command 3 4 1, msg 1/1)
1/2 Command + Subcommand = 0x57
1/3 Total Number of Messages = 18
2/1 Aux. Status (see command 3 5 1, msg 2/1)
2/2 Iop A high byte (*800)
2/3 Iop A low byte
3/1 Iop B high byte (*800)
3/2 Iop B low byte
3/3 Iop C high byte (*800)
4/1 Iop C low byte
4/2 IresA-1 high byte (*800)
4/3 IresA-1 low byte
5/1 IresA-1 Angle high byte
5/2 IresA-1 Angle low byte
5/3 IresB-1 high byte (*800)
6/1 IresB-1 low byte
6/2 IresB-1 Angle high byte
6/3 IresB-1 Angle low byte
7/1 IresC-1 high byte (*800)
7/2 IresC-1 low byte
7/3 IresC-1 Angle high byte
8/1 IresC-1 Angle low byte
8/2 IresA-2 high byte (*800)
8/3 IresA-2 low byte
9/1 IresA-2 Angle high byte
9/2 IresA-2 Angle low byte
9/3 IresB-2 high byte (*800)
10/1 IresB-2 low byte
10/2 IresB-2 Angle high byte
10/3 IresB-2 Angle low byte
11/1 IresC-2 high byte (*800)
11/2 IresC-2 low byte
11/3 IresC-2 Angle high byte
