TPU2000/2000R Modbus/Modbus Plus/ Modbus TCP/IP Automation Guide
296
12/1 IresC-2 Angle low byte
12/2 2nd Harmonic % A-1 byte (*2)
12/3 2nd Harmonic % B-1 byte (*2)
13/1 2nd Harmonic % C-1 byte (*2)
13/2 2nd Harmonic % A-2 byte (*2)
13/3 2nd Harmonic % B-2 byte (*2)
14/1 2nd Harmonic % C-2 byte (*2)
14/2 5th Harmonic % A-1 byte (*2)
14/3 5th Harmonic % B-1 byte (*2)
15/1 5th Harmonic % C-1 byte (*2)
15/2 5th Harmonic % A-2 byte (*2)
15/3 5th Harmonic % B-2 byte (*2)
16/1 5th Harmonic % C-2 byte (*2)
16/2 All Harmonics % A-1 byte (*2)
16/3 All Harmonics % B-1 byte (*2)
17/1 All Harmonics % C-1 byte (*2)
17/2 All Harmonics % A-2 byte (*2)
17/3 All Harmonics % B-2 byte (*2)
18/1 All Harmonics % C-2 byte (*2)
18/2 Winding 1 Tap (*10)
18/3 Winding 2 Tap (*10)
5.8 Send First Differential Fault Record ( 3 5 8 )
The Differential Fault Record command returns data in two parts. This command requires a data byte message to indicate
which part of the record is to be returned. If the data message 1/2 = 0, part 1 of the record is returned. If the data message
1/2 = 1, part 2 of the record is returned.
Fault Type
Definitions
00 87T
01 87H
02 51P-1
03 51N-1
04 50P-1
05 50N-1
06 150P-1
07 150N-1
08 46-1
09 51P-2
10 51G-2
11 50P-2
12 50G-2
13 150P-2
14 150G-2
15 46-2
16 ECI-1
17 ECI-2
18 Thru Flt
19 Harm Rest
Data byte
1/1 0 = Reserved for Unreported Records
1/2 0 = Send part 1 of Record, 1 = Send part 2 of Record
1/3 Checksum 1/1 + 1/2
Msg byte
Definition-Part 1 of Record
1/1 Relay Status (see command 3 4 1, msg 1/1)
1/2 Command + Subcommand = 0x58
1/3 Total Number of Messages = 28
