TPU2000/2000R Modbus/Modbus Plus/ Modbus TCP/IP Automation Guide
298
21/3 I restraint C-1 (Ang) Hi byte
22/1 I restraint C-1 (Ang) Lo byte
22/2 I restraint A-2 (Ang) Hi byte
22/3 I restraint A-2 (Ang) Lo byte
23/1 I restraint B-2 (Ang) Hi byte
23/2 I restraint B-2 (Ang) Lo byte
23/3 I restraint C-2 (Ang) Hi byte
24/1 I restraint C-2 (Ang) Lo byte
24/2 Spare
24/3 Spare
25/1 Spare
25/2 Spare
25/3 Spare
26/1 Spare
26/2 Spare
26/3 Spare
27/1 Spare
27/2 Spare
27/3 Spare
28/1 Spare
28/2 Spare
28/3 Spare
Data byte
See previous
Msg byte
Definition-Part 2 of Record
1/1 Relay Status (see command 3 4 1, msg 1/1)
1/2 Command + Subcommand = 0x58
1/3 Total Number of Messages = 28
2/1 Param Flag high byte
2/2 Param Flag low byte
2/3 Fault Type (element)
3/1 Setting
3/2 Fault Number (high byte)
3/3 Fault Number (low byte)
4/1 Year
4/2 Month
4/3 Day
5/1 Hours
5/2 Minutes
5/3 Seconds
6/1 Hundredths of seconds
6/2 Clear Time Hi byte (*1000)
6/3 Clear Time Lo byte
7/1 I A-1 high byte (*800 / Phase Wdg1 Scale)
7/2 I A-1 low byte
7/3 I B-1 high byte (*800 / Phase Wdg1 Scale)
8/1 I B-1 low byte
8/2 I C-1 high byte (*800 / Phase Wdg1 Scale)
8/3 I C-1 low byte
9/1 I N-1 high byte (*800 / Neutral Wdg1 Scale)
9/2 I N-1 low byte
9/3 I A-2 high byte (*800 / Phase Wdg2 Scale)
10/1 I A-2 low byte
10/2 I B-2 high byte (*800 / Phase Wdg2 Scale)
10/3 I B-2 low byte
11/1 I C-2 high byte (*800 / Phase Wdg2 Scale)
11/2 I C-2 low byte
