TPU2000/2000R Modbus/Modbus Plus Automation Guide
299
11/3 I G-2 high byte (*800 / Ground Wdg2 Scale)
12/1 I G-2 low byte
12/2 Spare
12/3 I A-1 (ang) high byte
13/1 I A-1 (ang) low byte
13/2 I B-1 (ang) high byte
13/3 I B-1 (ang) low byte
14/1 I C-1 (ang) high byte
14/2 I C-1 (ang) low byte
14/3 I N-1 (ang) high byte
15/1 I N-1 (ang) low byte
15/2 I A-2 (ang) high byte
15/3 I A-2 (ang) low byte
16/1 I B-2 (ang) high byte
16/2 I B-2 (ang) low byte
16/3 I C-2 (ang) high byte
17/1 I C-2 (ang) low byte
17/2 I G-2 (ang) high byte
17/3 I G-2 (ang) low byte
18/1 I 0-1 high byte (*800 / Phase Wdg1 Scale)
18/2 I 0-1 low byte
18/3 I 1-1 high byte (*800 / Phase Wdg1 Scale)
19/1 I 1-1 low byte
19/2 I 2-1 high byte (*800 / Phase Wdg1 Scale)
19/3 I 2-1 low byte
20/1 I 0-2 high byte (*800 / Phase Wdg2 Scale)
20/2 I 0-2 low byte
20/3 I 1-2 high byte (*800 / Phase Wdg2 Scale)
21/1 I 1-2 low byte
21/2 I 2-2 high byte (*800 / Phase Wdg2 Scale)
21/3 I 2-2 low byte
22/1 I 0-1 (ang) high byte
22/2 I 0-1 (ang) low byte
22/3 I 1-1 (ang) high byte
23/1 I 1-1 (ang) low byte
23/2 I 2-1 (ang) high byte
23/3 I 2-1 (ang) low byte
24/1 I 0-2 (ang) high byte
24/2 I 0-2 (ang) low byte
24/3 I 1-2 (ang) high byte
25/1 I 1-2 (ang) low byte
25/2 I 2-2 (ang) high byte
25/3 I 2-2 (ang) low byte
26/1 Scale - Phase Wdg 1 high byte
26/2 Scale - Phase Wdg 1 low byte
26/3 Scale - Phase Wdg 2 high byte
27/1 Scale - Phase Wdg 2 low byte
27/2 Scale - Neutral Wdg 1 high byte
27/3 Scale - Neutral Wdg 1 low byte
28/1 Scale - Ground Wdg 2 high byte
28/2 Scale - Ground Wdg 2 low byte
28/3 Spare
If no fault data entry is present then send all 0s for 2/1 through 27/3.
5.9 Send Next Differential Fault Record ( 3 5 9 )
Same format as ( 3 5 8 ) except Msg 1/2 = 0x59.
